G150

u-blox LENA R8 operates on all major global 4G Cat 1bis and 2G bands

Supported 4G Cat 1bis bands:
B1, B2, B3, B4, B5, B7, B8, B12, B20, B28, B38, B40, B41, B66

Quad-band 2G support for global 2G networks

Bluetooth 5.2 gateway reports nearby Bluetooth tags and sensors.

Internal Nano 4FF SIM

u-blox M10

Concurrent GPS, GLONASS, Galileo, BeiDou

GNSS almanac and ephemeris data for greater sensitivity and position accuracy.

GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail.

Cell tower fallback for positioning when there is no GNSS signal.

~2m CEP

* Positioning accuracy specifications are provided by the module supplier and reflect ideal conditions. Device configuration, installation, environmental conditions, augmentation services, and many other factors may lead to variations in positioning accuracy.

8-33V DC (max)

Stringent power “load dump” tests are conducted to ensure operation in the harshest automotive electrical systems. Built-in self-resetting fuse makes installation simple and safe.

Device enters sleep mode when vehicle is inactive to prevent battery drain.

<1mA (no peripherals supplied and battery fully charged)

3500mAh LiPo rechargeable battery.

180 x 119 x 39 mm (7.1 x 4.7 x 1.5 in)

Non-branded housing is suitable for white labeling.

Ultra-rugged and waterproof IP68 and IK08-rated housing ensures the device can withstand impact, fine dust, and brief submersion.

Allows for pressure equalization while protecting against water and dust ingress.

Device supplied with one 10-wired harness (1m). Secondary harness required to access full set of I/Os. For pin out and further details, see G150 Harness Definition.

Operating: -30°C to +60°C (connected to external power)
At < 0°C and > +40°C the internal backup battery will not be charged as a safety precaution due to the dangers associated with charging batteries at extreme temperatures.
Recommended Storage: 10°C to 30°C, Humidity 30%. Store in a cool, dry place.

Internal. Option to add high-gain external antenna.

 Internal

 3-Axis accelerometer to detect movement, high-g events, and more.

 Diagnostic LED indicates operation status.

Store records if device is out of cellular coverage. View storage capacity here.

Internal buzzer fitted for audible alerts for speeding, harsh driving, driver ID reminders, error conditions, input feedback, and other events.

The device continuously monitors speed and heading, allowing for over-speed alerts as well as updates on speed and heading changes.

The device reports internal temperature and prevents the internal battery from charging in extreme temperatures. May not be suitable for precise temperature

1 x 0 - 30V Analog Input
Auto Ranging, 12-bit ADC
0 - 5V range: 1.22mV resolution
0 - 30V range: 7.32mV resolution

4 x Digital Inputs
Configurable pull-up/down
0-48V DC Input Range

2 x Switched Ground Digital Outputs

Easily wired up to switch external lights, relays, buzzers, etc. Can also be used to immobilize a vehicle.

1 x dedicated ignition Digital Input 0-48V DC
2.2V on threshold
May be used as a digital input if not required

Can be used to connect Iridium Edge® Module or interface with controllers and other sensors.

Outputs are either 5V (external power connected) or Vbatt (no external power) Max Current: 400mA

The G150 can provide power to external peripherals, eliminating the need for additional external power supplies.

Serial interface used to connect a Digital Matter RFID reader for Driver ID.

Wiegand Interface enables easy integration with a variety of RFID card types and readers.

1-Wire® or iButton® can be used to read Driver ID tags. Readers available to suit multiple card formats.

Configure accident and rollover alerts, triggered by extreme changes in the velocity and orientation of the vehicle or equipment. Up to 2 hours of second-by-second ‘black box’ data is stored to provide critical accident reconstruction data.

Bluetooth®, RFID reader, iButton®, or Wiegand interface for Driver ID, access control, and log booking.

Monitor speeding, harsh acceleration, braking, cornering, idle times and more to improve safety and prevent unnecessary wear on vehicles.

Interface with a range of devices and switches for seatbelt detection, duress and panic buttons, lights, in-cab warning buzzers, and more.

The server can use device location to create geofences and alerts if an asset enters or leaves designated locations. Geofences can also be downloaded directly to the device for enhanced location-based actions and alerts. View storage capacity here.

GPS jamming or interference can be detected and alerted on.

Can be wired up to external buzzers or lights for in-vehicle alerts.

Fit the G150 with an optional Iridium Edge® Module using the RS232 connection to track assets in remote areas outside of cellular coverage.

Set reminders based on distance travelled and run hours to reduce maintenance and repair costs.

Device remains continuously connected while on the move for real-time asset tracking.

Digital outputs can be connected to a relay to enable remote immobilization of vehicles and equipment in the case of theft, abuse, or unauthorized usage.

Interface a variety of duress pendants to enable man-down alerts for remote (out-of-coverage) worker safety monitoring. Requires Iridium Edge® Module.

Capture run-hours based on movement to understand and optimize asset utilization.

Instant alert if the device is disconnected from its power source.

Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.

Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application.

Manage, monitor, configure, debug, update, and restart devices remotely from our cloud-based device management system.

Configurable with DM-Link provisioning tool.

TCP Direct or HTTPS Webhook

Command and configure the device via rich API functionality.

Military-grade AES-256 Encryption from device to Device Manager to protect the integrity and confidentiality of your data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security.

Two-year manufacturer’s warranty. Exclusions apply.
