Barra Core

The Quectel BC660K-GL is a high-performance NB-IoT (NB2) module which supports multiple frequency bands of:

B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66/B70/B85

 Internal Nano 4FF SIM

Semtech LR1110

Indoor/Outdoor

Indoor asset location using Wi-Fi access point scanning.

Cell tower fallback for positioning when there is no Wi-Fi signal.

Asset location is resolved using Digital Matter’s Location Engine.

~10m-100m with Wi-Fi in urban areas
~250m-1km Cell Tower Geolocation - dependent on number of nearby towers

* Positioning accuracy specifications are provided by the module supplier and reflect ideal conditions. Device configuration, installation, environmental conditions, augmentation services, and many other factors may lead to variations in positioning accuracy.

2 x AA. Batteries not included.
Widely available at most hardware or retail locations.

Lithium
Battery selection is very important. Follow this link to learn more. Please dispose of Lithium batteries in a safe and responsible manner.

Once Daily location updates – 10 years
Movement-Based location updates** – 4.5 years
Hourly location updates – 3 years

<10uA
Average current in lowest power state.

* Battery life estimates are influenced by several factors including temperature, installation and orientation of the device, battery selection, the frequency of location updates, network coverage, sensor integrations, peripherals, accelerometer settings, and more. Battery life calculators are available at support.digitalmatter.com.

** Movement-based estimates are based on 2 hours of movement, occurring 5 days a week, with default trip tracking parameters (location updates every 3 minutes and uploads every 30 minutes). Devices can be configured to provide more frequent location updates when the asset is in motion which will impact battery life.

 149 x 51 x 21 mm (5.9 x 2 x 0.8 in)

98g with Energizer Ultimate Lithium batteries.

Non-branded nylon glass housing is suitable for white labeling.

Ultra-rugged and waterproof IP68 and IK07-rated housing ensures the device can withstand impact, fine dust, and brief submersion.

Compact and concealable. Multiple installation options for covertly and easily securing the device to assets with screws, bolts, cable ties, rivets, and more. Stainless steel screws provided.

Removal of magnet enables quick activation and tamper detection.

Operating: -30°C to +60°C
Recommended Storage: 10°C to 30°C, Humidity 30%.
Store in a cool, dry place.

Internal

Internal

3-Axis accelerometer to detect movement, high-g events, and more.

Diagnostic LED indicates operation status.

Store records if device is out of cellular coverage. View storage capacity here.

Scanning technology used on this device does not return speed or heading.

Provides ambient temperature but may not be suitable for precise temperature logging purposes.

Configure parameters to send updates based on set time intervals or when movement occurs. Adaptive tracking technology detects when the device is on the move and increases the update rate, providing detail when you need it while conserving battery when stationary.

‘Battery Low’ and ‘Battery Critical’ alert levels.

The server can use device location to create geofences and alerts if an asset enters or leaves designated locations.

Configure impact-detection alerts when g-forces are exceeded by a user-defined threshold.

Removal of the magnet can be used to activate the unit, enabling the pre-provisioning of SIM cards and batteries.

Capture run hours based on movement to understand and optimize asset utilization.

External magnet provides an alert if the device is removed from your asset.

Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.

Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application.

Manage, monitor, configure, debug, update, and restart devices remotely from our cloud-based device management system.

Configurable with DM-Link provisioning tool.

HTTPS Webhook

Command and configure the device via rich API functionality.

Military-grade AES-256 Encryption from device to Device Manager to protect the integrity and confidentiality of your data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security.

Two-year manufacturer’s warranty. Exclusions apply.
